Product details
1. High light LED Chips, low light degradation and long lifespan, CRI>80
2. Anti-UV PC cover, excellent yellowing resistance, and durable
3. Environmental ABS material shell
3. IP68 Structure waterproof, without resin-filled.
4. Patented 4-layers waterproof structure, more stable than resin-filled pool lights
5. VDE standard rubber wire, connected with IP68 nickel-plated copper connector.
6. All products succeeded in 10m deep water testing before delivery.
7. 8 hours aging testing, 30 steps quality inspections, assure the great quality pool light.
| HG-PL-18X1W-F1-RGB-T |
| Lamp paramater | Material | ABS + Transparent PC cover |
| Light dimension | Φ290×85mm |
| Input voltage | AC12 |
| Wattage | 18W±10％ |
| Light lumen | 630LM±10％ |
| Halogen replacement | / |
| Beam angle | 120° |
| BASE | Wire out |
| CCT | RGB |
| Specifics | Operating Temperature (℃) | -20~40℃ |
| IP Rating | IP68 |
| Certificate | CE, ROHS,FCC, IP68,VDE |
| Life-span | 50,000 hours |
| Warranty | 2 Years |
| !!! Remarks | Connect coil transformer | must be coil transformer |
| Waterproof ring of housing | must do right to get IP68 |
| Connect our RGB 100% Synchronous Controller | Input Voltage | AC110/120/220Vcoil transformer |
| Wattage | 1.5W |
| cable | 2 wires |
| Control way | Synchronous control effect |
| Test position | LED Surface Mounted Swimming Pool Light(Min) |
| Working temperature 28℃ | Working temperature 40℃ |
| Underwater test time(Min) | 480 | 480 |
| LED edge temperature(℃) | 46 | 57 | 65 | 65 | 56 | 66 | 68 | 70 |
Application
Surface mounted pool lights application: Concrete pool ,Vinyl pool ,Outdoor Swimming Pool,
family pool,hotel pool, underwater etc.
Advantage
1. Reliable quality with 100% 10m depth waterproof test.
2. Must be 8 hours aging test.
3. Finished products all passed 30 steps quality inspection
4. IP68 structure waterproof, can long time use underwater.
5. Constant current driver, comply with CE & EMC standard.
What information should I let you know when I want to make a inquiry?
1.What color do you want?
4.Which voltage ( low voltage or high voltage)?
5.What kind of beam angle did you need?
6.How many quantity do you need?
